DB200H/DB200-210 FEATURES
8 - POWER SWITCH - Switches the power to the AMP .
9 - GROUND LIFT – Provided to avoid any hum problems there may be when connecting
the balanced D.I to external equipment such as mixing desks etc.
10 - SOURCE SWITCH - Selects the signal sent to the Balanced D.I. out. Can be set to PRE,
only sending the input signal to the AMP , or POST sending the signal after the Preamp,
EQ and TILT sections.
11 - XLR-Balanced D.I. Out– XLR-Balanced D.I. Out – This is a balanced signal output for
sending to external devices such as mixing desking, PA etc.
12 - PHONES SOCKET – Connecting headphones for monitoring or silent practice.
13 - AUX IN – Provided for connecting an external sound source. Useful for jamming along
with audio tracks.
14 - FX LOOP SEND & RETURN - These sockets are used for connecting an external effects
device to your amplifier. Use the send jack to connect to the input of your external
device and use the return jack to connect the output of the external device to your
amplifier.
15 – COMBI Socket – Speakon NL2 compatible twist lock and 6.3mm jack. Provided to
connect your external cabinet. Please make sure the total cabinet impedance is no
less than 4 ohms i.e. you can use a single 4 Ohm rated cabinet or 2 x 8 Ohm rated
cabinets may be used. *Not present on the DB200-210.
11
10
8
9
13
11
12
USER MANUAL EN
*
14
15
www.laney.co.uk
