Sharpness adjustment (fig. 3 and 4)
•
Place the projector in a way that the lens is perpendicular to the wall or
screen the image is to be displayed on.
•
To correct sharpness of the image, rotate the sharpness knob on the top
panel (1) until the picture gets clear.
•
If the image is not displayed perpendicularly, it will be distorted.
Picture shape adjustment
Distorted picture in the shape of trapezoid can be corrected with the use of
a picture shape adjustment knob (2).
X
- wrong shape
✔- correct shape
Note! The projector features a vertical trapezoid correction only. There is no
horizontal correction. Make sure the projector is positioned on a horizontal
surface in relation to the picture.
Menu settings (fig. 5)
When you press the left/right key on the remote control or projector, the
submenu will displayed in the main interface, select the desired mode and
press „OK" to confirm.
Options to choose:
•
PICTURE: picture mode, contrast, brightness, color, tint, sharpness, color
temperature, noise reduction.
•
SOUND: volume mode, bass.
•
OTHER OPTIONS: language, ratio, projection mode, restore factory
settings, update software, version.
Select source (fig. 6)
Step 1: Switch the projector on. Main interface will be displayed.
Step 2: Select a source from the list displayed, e.g. HDMI or AV, and confirm
with „OK" key.
Note! When there is no signal, press source key on the remote control to choose
homepage or other source.
Multimedia support (fig. 7)
Step 1: Connect a USB cable to projector.
Step 2: Select file to be played in the main interface.
