Status
As you play back or record a clip, this indicator will display the transport control status and
controls currently being used. These include:
HyperDeck is in standby mode.
Video is being played.
Video is being recorded.
The indicator will illuminate
red during recording.
Displayed during fast forward
or rewind. The numbers indicate
the speed.
Storage Media Status
These three indicators display the name and status of the SD card, SSDs and active USB drive
and vary slightly depending on the HyperDeck model.
HyperDeck
Studio HD Plus
HyperDeck
Studio Pro Models
On all HyperDeck models, the third indicator displays the USB drive. If you are using a USB hub,
or a dock such as Blackmagic MultiDock 10G, the active drive will be displayed.
Disk or Drive Indicator
The text above the progress bar indicates the SD card slot or SSD slot. If you are
recording, 'current' will appear to the left of the drive so you can easily identify which
disk is recording. 'Next' will appear above the progress bar to indicate the next disk or
drive to be recorded to.
SD Card slot 1
Current SD or SSD
slot in use
Indicates playback is set to 'loop'
all recorded clips sharing the
currently selected video format.
Indicates playback is set to loop
a single clip.
Indicates shuttle mode is
enabled, but in standby.
HyperDeck is in jog mode.
HyperDeck is in scroll mode.
SD Card slot 2 Active external disk
Next SD or SSD Active external disk
slot in order
