Vor dem Einbau des Heizkessel-Anbindesystems
die Einbau- und Betriebsanleitung vollständig
lesen!
Einbau, Inbetriebnahme, Bedienung und Wartung
darf nur durch geschultes Fachpersonal durch-
geführt werden!
Die Einbau- und Betriebsanleitung sowie alle
mitgeltenden Unterlagen sind an den Anlagen-
betreiber weiterzugeben!
Inhalt:
1
Allgemeine Hinweise .................................... 1
2
Sicherheitshinweise ...................................... 2
3
4
Technische Daten ........................................ 2
5
Aufbau und Funktion .................................... 4
6
Einbau .......................................................... 5
6.1
Wandmontage .............................................. 6
6.2
6.2.2 Umbau Stellmotor ........................................ 8
6.2.3 Umbau 3-Wege-Mischhahn ....................... 10
6.3
6.4
6.5
7
Betrieb ......................................................... 14
8
Wartung und Pflege .................................... 14
9
und Lieferung .............................................. 14
Abb. 1 Pumpengruppe mit 3-Wege-Mischhahn DN25
(Auslieferung je nach Ausführung mit oder ohne
Lüftungsgitter möglich).
Heizkessel-Anbindesystem DN 25
Einbau- und Betriebsanleitung für Fachpersonal

1 Allgemeine Hinweise

1.1 Informationen zur Einbau- und Betriebsanlei-
tung
Diese Einbau- und Betriebsanleitung dient dem ge-
schulten Fachpersonal dazu, das Heizkessel-Anbin-
desystem fachgerecht zu installieren und in Betrieb zu
nehmen.
Mitgeltende Unterlagen - Anleitungen aller Anlagen-
komponenten, insbesondere die Bedienungsanlei-
tung der Hocheffizienzpumpe, sowie geltende techni-
sche Regeln - sind einzuhalten.
1.2 Aufbewahrung der Unterlagen
Diese Einbau- und Betriebsanleitung ist vom Anlagen-
betreiber zum späteren Gebrauch aufzubewahren.
1.3 Urheberschutz
Die Einbau- und Betriebsanleitung ist urheberrechtlich
geschützt.
1.4 Symbolerklärung
Hinweise zur Sicherheit sind durch Symbole gekenn-
zeichnet. Diese Hinweise sind zu befolgen, um Un-
fälle, Sachschäden und Störungen zu vermeiden.
!
GEFAHR
mittelbar gefährliche Situation hin, die zum Tod oder
zu schweren Verletzungen führen wird, wenn die
Sicherheitsmaßnahmen nicht befolgt werden.
!
WARNUNG
möglicherweise gefährliche Situation hin, die zum Tod
oder zu schweren Verletzungen führen kann, wenn die
Sicherheitsmaßnahmen nicht befolgt werden.
!
VORSICHT
möglicherweise gefährliche Situation hin, die zu ge-
ringfügigen oder leichten Verletzungen führen kann,
wenn die Sicherheitsmaßnahmen nicht befolgt wer-
den.
ACHTUNG
che Sachschäden hin, welche entstehen können,
wenn die Sicherheitsmaßnahmen nicht befolgt wer-
den.
Technische Änderungen vorbehalten.
168952080
02/2019
GEFAHR weist auf eine un-
WARNUNG weist auf eine
VORSICHT weist auf eine
ACHTUNG weist auf mögli-
