Caratteristiche di funzionamento
Pressione di servizio ideale: ..................... 3 bar
Pressione di servizio massimo: ............................ 5 bar
Temperatura acqua calda ideale: ........................ 60° C
Temperatura acqua calda massima: ................... 70° C
Attenzione:
Risciacquare bene le tubazioni prima del montaggio.
F
Caractéristiques de fonctionnement
Pression de service idéale: ...................... 3 bar
Pression de service max.: .................................... 5 bar
Température idéale de l'eau: ............................... 60° C
Température max. de l'eau: ................................. 70° C
Attention:
Rincer à fond la tuyauterie avant le montage.
REDM10I
MAX.
81mm
MIN.
3" 3/16
57mm
2" 1/4
Dimensioni d'ingombro e quote di fissaggio
Overall dimensions and fixing points
Dimensions d'encombrement et fixations
Maßen und Befestigungshöhe
Ø45mm
Ø1" 49/64
70mm
2" 3/4
14,5mm
14,5mm
37/64"
37/64"
9,5mm
3/8"
9,5mm
3/8"
GB
Operating data
Ideal operating pressure: .......................... 3 bar
Max. operating pressure: ...................................... 5 bar
Ideal water temperature:...................................... 60° C
Max. water temperature:...................................... 70° C
Attention:
Before installation flush pipes thoroughly.
D
Betriebsdaten:
Idealer Betriebsdruck: .............................. 3 bar
Max. Betriebsdruck: .............................................. 5 bar
Ideale Wassertemperatur: ................................... 60° C
Max. Wassertemperatur: ..................................... 70° C
Achtung:
Vor Montage die Leitungen gründlich durchspülen.
05/15
19,5mm
49/64"
109mm
4" 19/64
-2-
1/2" GAS (EU)
1/2" NPT (USA)
54,5mm
2" 9/64
54,5mm
2" 9/64
