Mounting
Before mounting this product, read the
Mounting Diagram
Control Panel Description
BUTTON FUNCTION
<MENU> Exits from the current menu or function
<UP> Navigates upwards through the menu list and increases the numeric value when in a function
<DOWN> Navigates downwards through the menu list and decreases the numeric value when in a function
<ENTER> Enables the currently displayed menu or sets the currently selected value into the selected function
Menu Map
Refer to the Intimidator Spot 375Z IRC product page on
MAIN LEVEL PROGRAMMING LEVELS
Address
DMX
Slave
Run Mode
Manual
3
QUICK REFERENCE GUIDE
Safety Notes.
Mounting Clamp
(such as CLP-15 from Chauvet)
Mounting Bracket
Safety Cable
(such as CH-05 from
Chauvet)
Rubber Feet for Floor Mounting
www.chauvetdj.com
001–512
15CH
09CH
Slave1–4
Auto
Sound
IR
Pan
Tilt
Color
Gobo
Gobo Rotate
000–255
Prism
Focus
Zoom
Dimmer
Shutter
(x4)
for the latest menu map.
DESCRIPTION
Sets the DMX starting address
Selects DMX mode
Selects Slave mode 1, 2, 3, or 4
Selects Auto mode
Selects Sound-Active mode
Selects infrared control
0 to 540°
0 to 270°
Selects color options
Selects gobo options
Rotates gobo
Selects prism and rotation effect
Manual focus control
Manual zoom control
Sets dimmer value
Sets shutter value and strobe effect
