QUICK REFERENCE GUIDE About This Guide The Intimidator Spot 375Z IRC Quick Reference Guide (QRG) has basic product information such as mounting, menu options, and DMX values. Download the User Manual from www.chauvetdj.com for more details. Disclaimer The information and specifications contained in this QRG are subject to change without notice.
Chauvet. Product Description The Intimidator Spot 375Z IRC is a 150 W LED moving head light with motorized focus and zoom for crisp gobo and beam changing effects. Built-in automatic programs along with move-in-black capability provide flexibility and easy programming to create powerful eye candy quickly and beautifully.
Seite 4
Navigates downwards through the menu list and decreases the numeric value when in a function <ENTER> Enables the currently displayed menu or sets the currently selected value into the selected function Menu Map Refer to the Intimidator Spot 375Z IRC product page on www.chauvetdj.com for the latest menu map. MAIN LEVEL...
Seite 5
DMX Linking The Intimidator Spot 375Z IRC can work with a DMX controller. Instructions for connecting and configuring this product for DMX operation are in the User Manual. If you are not familiar with DMX, download the DMX Primer from www.chauvetdj.com.
Reverse cycle effect, slow to fast No function Gobo indexing Rotation, slow to fast Gobo Rotation Stop Reverse rotation, slow to fast Bounce, slow to fast Intimidator Spot 375Z IRC QRG Rev. 5...
Seite 7
Movement macro 5 Movement Macros Movement macro 6 Movement macro 7 Movement macro 8 Sound-active movement macro 1 Sound-active movement macro 2 Sound-active movement macro 3 Intimidator Spot 375Z IRC QRG Rev. 5...
Seite 8
Reverse cycle effect, slow to fast No function Gobo indexing Rotation, slow to fast Gobo Rotation Stop Reverse rotation, slow to fast Bounce, slow to fast Intimidator Spot 375Z IRC QRG Rev. 5...
Seite 9
Focus, big to small Closed Open Strobe, slow to fast Shutter Pulse strobe, slow to fast Random strobe, slow to fast Open Zoom Zoom out to zoom in Intimidator Spot 375Z IRC QRG Rev. 5...
GUÍA DE REFERENCIA RÁPIDA Acerca de esta guía La Guía de referencia rápida (GRR) del Intimidator Spot 375Z IRC contiene información básica sobre el producto, como montaje, opciones de menú y valores DMX. Descargue el manual de usuario de www.chauvetdj.com para una información más detallada.
Descripción del producto El Intimidator Spot 375Z IRC es una luz LED de cabeza móvil de 150 W, con enfoque y zoom con motor, para efectos de haces cambiantes y gobos nítidos. Los programas automáticos integrados, junto con la capacidad move-in-black proporcionan flexibilidad y programación fácil para crear atracciones visuales bonitas y potentes de forma rápida.
Seite 12
Habilita el menú actualmente en pantalla o configura el valor seleccionado actualmente dentro de la <ENTER> función seleccionada Mapa de menú Consulte la página del producto Intimidator Spot 375Z IRC en www.chauvetdj.com para ver el último mapa de menu. NIVEL NIVELES DE PROGRAMACIÓN...
Seite 13
Enlace DMX El Intimidator Spot 375Z IRC puede funcionar con un controlador DMX cuando se enlaza por conexiones serie DMX. Las instrucciones para conectar y configurar este producto para funcionamiento DMX están en el Manual de usuario. Si no está...
Seite 14
Vibración gobo 3, lento a rápido Vibración gobo 2, lento a rápido Vibración gobo 1, lento a rápido Abierto Efecto cíclico, lento a rápido Parada Efecto cíclico inverso, lento a rápido Intimidator Spot 375Z IRC GRR Rev. 5...
Seite 15
Reiniciar desplazamiento lateral Reiniciar inclinación Reiniciar rueda de color Reiniciar rueda de gobo Sin función Reiniciar prisma Reiniciar foco y zoom Reiniciar todos Sin función Intimidator Spot 375Z IRC GRR Rev. 5...
Seite 16
Rueda de color Magenta Amarillo Blanco Indexación de color Ciclo de color arco iris, rápido a lento Parada Ciclo de color arco iris inverso, lento a rápido Intimidator Spot 375Z IRC GRR Rev. 5...
Seite 17
Cerrado Abierto Estroboscopio, lento a rápido Obturador Estroboscopio de pulso, lento a rápido Estroboscopio aleatorio, lento a rápido Abierto Zoom Disminuir zoom a aumentar zoom Intimidator Spot 375Z IRC GRR Rev. 5...
A propos de ce manuel Le Manuel de Référence (MR) du Intimidator Spot 375Z IRC reprend des informations de base sur cet appareil notamment en matière de montage, d'options de menu et de valeurs DMX. Veuillez télécharger le manuel d'utilisation à...
Description de l'appareil Le Intimidator Spot 375Z IRC est une lampe LED 150 W à tête mobile avec une mise au point et un zoom motorisés permettant d'obtenir des gobos bien définis et de projeter des effets changeants. Des programmes automatiques intégrés et la fonctionnalité...
Active l'entrée de menu actuellement affichée ou confirme la valeur actuellement sélectionnée pour la <ENTER> fonction en cours de sélection Menu carte Reportez-vous à la page du produit Intimidator Spot 375Z IRC sur www.chauvetdj.com pour la demière carte des menu. FONCTION...
Seite 21
Chaînage DMX Le Intimidator Spot 375Z IRC peut fonctionner avec un contrôleur DMX lorsqu'il est relié par des connexions séries DMX. Les instructions pour la connexion et la configuration de cet appareil pour le fonctionnement en DMX sont indiquées dans le manuel d'utilisation.
Seite 22
Tremblement du gobo 2, lent à rapide Tremblement du gobo 1, lent à rapide Ouvert Effet de cycle, lent à rapide Arrêt Effet de cycle inversé, lent à rapide Intimidator Spot 375Z IRC MR Rév. 5...
Seite 23
Réinitialisation de la roue de couleurs Réinitialisation de la roue de gobos Aucune fonction Réinitialisation du prisme Réinitialisation de focus et zoom Réinitialisation de tous Aucune fonction Intimidator Spot 375Z IRC MR Rév. 5...
Seite 24
Roue de couleurs Magenta Jaune Blanc Indexation des couleurs Arc-en-ciel de couleur en cycle, rapide à lent Arrêt Arc-en-ciel de couleur en cycle inverse, lent à rapide Intimidator Spot 375Z IRC MR Rév. 5...
Seite 25
Fermé Ouvert Stroboscope, lent à rapide Obturateur Stroboscope à pulsation, lent à rapide Stroboscope aléatoire, lent à rapide Ouvert Zoom Zoom arrière à zoom avant Intimidator Spot 375Z IRC MR Rév. 5...
SCHNELLANLEITUNG Über diese Schnellanleitung In der Schnellanleitung des Intimidator Spot 375Z IRC finden Sie die wesentlichen Produktinformationen, wie etwa über die Montage, Menüoptionen und DMX-Werte des Geräts. Laden Sie für weiterführende Informationen unter www.chauvetdj.com das Benutzerhandbuch herunter. Haftungsausschluss Die in dieser Anleitung aufgeführten Informationen und Spezifikationen können ohne vorherige Ankündigung geändert werden.
Wenn die Verpackung beschädigt ist, benachrichtigen Sie umgehend das Transportunternehmen, nicht jedoch Chauvet. Produktbeschreibung Der Intimidator Spot 375Z IRC ist ein LED-Moving Head mit 150 Watt und einem motorbetriebenen Fokus und Zoom für scharfe Gobo- und Strahländerungs-Effekte. Die integrierten Auto-Programme und die MIB-Funktion (Bewegung bei Dunkelheit) ermöglichen ein Plus an Flexibilität und eine einfachere Programmierung für die schnelle Erzeugung...
Seite 28
Damit navigieren Sie durch die Menüpunkte nach unten und verringern den numerischen Wert der <DOWN> entsprechenden Funktionen <ENTER> Aktiviert eine Menüoption oder einen ausgewählten Wert Menükarte Die neues te Menükarte finden Sie auf der Intimidator Spot 375Z IRC-produktseite unter www.chauvetdj.com. MAIN LEVEL PROGRAMMING LEVELS DESCRIPTION Address 001–512...
Zeigt die aktuelle Produkttemperatur an DMX-Verbindung Der Intimidator Spot 375Z IRC kann mit einem DMX-Controller betrieben werden, wenn eine DMX-Serienschaltung zum Einsatz kommt. Anweisungen zum Zusammenschluss und der Konfiguration dieses Geräts für den Betrieb im DMX- Modus finden Sie im Benutzerhandbuch. Wenn Sie mit DMX nicht vertraut sind, laden Sie "DMX - Eine Einführung" unter www.chauvetdj.com herunter.
Seite 30
Gobo 3 Shake, langsam bis schnell Gobo 2 Shake, langsam bis schnell Gobo 1 Shake, langsam bis schnell Offen Kreiseleffekt, langsam bis schnell Anhalten Kreiseleffekt in umgekehrter Richtung, langsam bis schnell Intimidator Spot 375Z IRC SAL Rev. 5...
Seite 31
Funktionen Keine Funktion Schwenkung zurücksetzen Neigung zurücksetzen Farbrad zurücksetzen Goborad zurücksetzen Keine Funktion Prisma zurücksetzen Fokus und Zoom zurücksetzen Alle zurücksetzen Keine Funktion Intimidator Spot 375Z IRC SAL Rev. 5...
GUIDA RAPIDA Informazioni sulla Guida La Guida Rapida Intimidator Spot 375Z IRC contiene informazioni di base sul prodotto quali montaggio, opzioni menù e valori DMX. Per maggiori dettagli, scaricare il Manuale Utente dal sito www.chauvetdj.com. Esclusione di responsabilità Le informazioni e le specifiche contenute in questa guida possono essere modificate senza preavviso.
Descrizione del prodotto Intimidator Spot 375Z IRC è un proiettore a testa mobile a LED da 150 W, con messa a fuoco motorizzata per gobo nitidi e zoom per effetti in movimento. I programmi integrati e la funzionalità "move-in-black" assicurano flessibilità e facile programmazione per creare eccezionali e potenti spettacoli in modo rapido.
Seite 36
Consente di spostarsi verso il basso nell'elenco menù e di diminuire il valore numerico all'interno di una funzione <ENTER> Consente di attivare il menù visualizzato o impostare il valore selezionato nella funzione selezionata Mappa menu Fare riferimento alla pagina del prodotto Intimidator Spot 375Z IRC su www.chauvetdj.com per la mappa dei menu più recente LIVELLO...
Seite 37
Per assicurare il completo accesso a tutti i canali in ciascuna modalità DMX, l'indirizzo maggiormente raccomandato è 498. Collegamento Master/Slave In modalità Master/Slave, Intimidator Spot 375Z IRC utilizza il collegamento dati DMX. Le istruzioni per il collegamento e la configurazione di questa unità per il funzionamento Master/Slave sono contenute nel Manuale Utente. IRC-6 (Telecomando a infrarossi) Intimidator Spot 375Z IRC è...
Seite 38
Oscillazione gobo 2, da lenta a veloce Oscillazione gobo 1, da lenta a veloce Aperto Effetto ciclico, da lenta a veloce Fermarsi Effetto ciclico inverso, da lenta a veloce Intimidator Spot 375Z IRC GR Rev. 5...
Seite 39
Reimpostazione rotazione Reimpostazione brandeggio Reimpostazione ruota colore Reimpostazione ruota gobo Nessuna funzione Reimpostazione prisma Reimpostazione messa a fuoco e zoom Reimpostazione di tutti Nessuna funzione Intimidator Spot 375Z IRC GR Rev. 5...
Seite 40
Ciano Rosso Verde Ruota colore Magenta Giallo White Indicizzazione colori Arcobaleno ciclico, da veloce a lento Fermarsi Arcobaleno ciclico inverso, da lento a veloce Intimidator Spot 375Z IRC GR Rev. 5...
Seite 41
Aperto Stroboscopio, da lento a veloce Otturatore Stroboscopio a impulso, da lento a veloce Stroboscopio casuale, da lento a veloce Aperto Zoom Diminuire zoom a aumentare zoom Intimidator Spot 375Z IRC GR Rev. 5...
BEKNOPTE HANDLEIDING Over deze handleiding De Intimidator Spot 375Z IRC Beknopte Handleiding (BH) bevat basisinformatie over het product, zoals montage, menu- opties en DMX-waarden. Download de gebruikershandleiding op www.chauvetdj.com voor meer informatie. Disclaimer De informatie en specificaties in deze BH kunnen zonder voorafgaande kennisgeving worden gewijzigd.
Beknopte handleiding Om te beginnen Pak uw Intimidator Spot 375Z IRC uit en zorg ervoor dat u alle onderdelen in goede staat hebt ontvangen. Als de doos of inhoud beschadigd lijkt, stel dan de vervoerder onmiddellijk op de hoogte, niet Chauvet.
Seite 44
<DOWN> Navigeert omlaag via het menu of verlaagt de numerieke waarde wanneer in een functie <ENTER> Activeert het huidige getoonde menu of plaatst de huidige geselecteerde waarde in de geselecteerde functie Menukaart Raadpleeg de productpagina van der Intimidator Spot 375Z IRC op www.chauvetdj.com voor de nieuwste menukaart.
Seite 45
Instructies voor het aansluiten en configureren van dit product voor DMX-bediening staan in de gebruikershandleiding. IRC-6 Infrarood Remote Control D Intimidator Spot 375Z IRC is compatibel met de IRC-6 infrarood afstandsbediening van CHAUVET DJ Ga voor meer informatie over de IRC-6 of downloadinstructies naar www.chauvetdj.com.
Seite 46
Gobo 3 schudden, langzaam tot snel Gobo 2 schudden, langzaam tot snel Gobo 1 schudden, langzaam tot snel Open Cyclus-effect, langzaam tot snel Stop Cyclus-effect omkeren, langzaam tot snel Intimidator Spot 375Z IRC BH Rev. 5...
Seite 47
Geen functie Functies Zwenken herstellen Kantelen herstellen Kleurenwiel herstellen Gobo-wiel herstellen Geen functie Prisma herstellen Focus en zoom herstellen Alle herstellen Geen functie Intimidator Spot 375Z IRC BH Rev. 5...
Seite 48
Oranje Limoengroen Cyaan Rood Groen Kleurenwiel Magenta Geel Kleur indexeren Kleur-cyclus regenboog, snel naar langzaam Stop Kleur-cyclus regenboog omkeren, langzaam naar snel Intimidator Spot 375Z IRC BH Rev. 5...
Seite 49
Focus, groot naar klein Gesloten Open Flitsen, langzaam naar snel Sluiter Impulse flitsen, langzaam naar snel Willekeurig flitsen, langzaam naar snel Open Zoom Zoom uit tot zoom in Intimidator Spot 375Z IRC BH Rev. 5...
