U.S. Robotics Wireless
Installation
Package Contents:
USR5421 Wireless MAXg USB Adapter
Quick Installation Guide
Rotation of the MAXg Wireless Adapter's flexible joint is limited by
stops that you can feel when you twist the joint. Do not force the
joint to twist past the point of resistance or damage may result. An
adapter that is damaged in this manner is not covered by the
warranty and may not be returned for a refund or exchange.
Prepare for installation
You must have administrator rights on your computer in order to install this product.
You will need to install this Installation CD-ROM on all the PCs on which you plan to install
Wireless MAXg USB Adapters.
You must be using Windows XP (Service Pack 1 or higher) or 2000 (Service Pack 4 or higher).
For the most updated information, visit: http://www.usr.com/support
You can also refer to the User Guide on the U.S. Robotics Installation CD-ROM for more detailed
information.
If you are installing only a Wireless MAXg USB Adapter, go to the
section entitled Installing JUST the Wireless MAXg USB Adapter.
Installing BOTH a Wireless MAXg R
Wireless MAXg USB Adapter
Step One: Connect the Wireless
A. Turn off your computer and your cable or DSL modem.
Disconnect the modem's Ethernet cable from your com-
puter and connect it to the WAN port of the Wireless
MAXg Router.
B. Connect the supplied Ethernet cable to the Network Interface Card of your computer and to
one of the LAN ports of the Wireless MAXg Router.
C. Connect the antenna to the Wireless MAXg Router.
MAX
g USB Adapter
Installation CD-ROM which includes User Guide
outer and
MAX
g Router
the
1
