Specification
Ambient Temperature:
-20°C to 50°C, -4°F to 122°F
Fluid Temperature:
-20°C to 100°C, -4°F to 212°F
Humidity:
95% RH
Fluid Type:
Hydraulic mineral oil to ISO 11158 category HM.
Maximum Operating Pressure:
Maximum full scale flow:
200 L/min, 53 gpm
Counter switch flow*:
10 L/min, 2.6 gpm
Switch Accuracy:
±4% of full scale
Display:
Permanently on 7mm high LCD digits
Run indicator:
Blinking decimal point
Resolution:
0.1 hour (6 minutes)
Timer Accuracy:
±0.2% over specified temperature range
Maximum count:
9999999.9 hours
Battery chemistry:
Lithium Thionyl Chloride
Battery life:
10+ years
IP Rating:
Designed for IP66 protection of electrical circuits
Flow body & housing:
Aluminium 2011T6 (anodised)
Internal parts:
Stainless steel and brass
Seals:
FKM (on adapters)
webtec.com
420 bar, 6000 psi
* The count trigger point is set using ISO32 oil at 50°C (21cSt).
Higher viscosities will decrease the switching flow and lower
viscosities will increase the switching flow.
3
