Safety instructions

Use

Device overview
Construction and dimensions
87 ± 5 mm
The electrode is only intended for the above-mentioned purpose.
The manufacturer is not liable for damage resulting from improper
use.
Respect the following instructions, otherwise the electrode may be
damaged or the measurement results may be falsified.
When working with chemicals, all relevant safety regulations of the
manufacturer and the laboratory must be respected.
Screw cap, L = 6,2 mm
Electrode head PTFE,
Socket for 2 mm banana plug
Thread G 1/8
L = 8 mm
Electrode shaft PEEK
Ø = 1,6 mm
L = 53,5 ± 0,5 mm
Contact wire
Hydrogen electrode
ø
20 mm
EN - Page 3
30 mm
