Boffi Pipe RGFP02E Montage Und Service Seite 3

RGFP02E
100mm
3" 15/16
96mm
3" 25/32
RIFP03:
150mm
5" 29/32
RIFP04:
220mm
8" 21/32
Dimensioni d'ingombro e quote di fissaggio
Overall dimensions and fixing points
Dimensions d'encombrement et fixations
Maßen und Befestigungshöhe
100mm
3" 15/16
245mm
9" 41/64
Ø 25mm
Ø 63/64"
Ø60mm
Ø2" 23/64
Ø70mm
Ø2" 3/4
Ø80mm
Ø3" 5/32
Ø 50mm
Ø 1" 31/32
40mm
1" 37/64
40mm
1" 37/64
MIN.
91mm
3" 37/64
MAX.
109mm
4" 19/64
3mm
1/8"
13mm
33/64"
36mm
18mm
1" 27/64
45/64"
5mm
13/64"
-3-
