Adjustment of a Constant Voltage (C.V.):
•
Turn STROM GROB [5] clockwise up to the stop.
•
Turn SPANNUNG GROB [8] counter clockwise to the stop.
•
Switch the device on with AN/AUS [3].
•
Now the green LED SPANNUNG BEGRENZUNG [7] should show.
•
Now adjust the desired output voltage with SPANNUNG GROB [8], SPANNUNG FEIN [9] and the help of
the display [2].
•
Connect the load to the terminals [10 & 11] of this device.
Adjustment of a Constant Current (C.C.):
•
Turn STROM GROB [5] clockwise up to the stop.
•
Turn SPANNUNG GROB [8] counter clockwise to the stop.
•
Switch the device on with AN/AUS [3].
•
Now the green LED SPANNUNG BEGRENZUNG [7] should show.
•
Short circuit the terminals by connecting the jacks [11] and [10] with a wire.
•
Turn SPANNUNG GROB [5] clockwise until the red LED STROM BEGRENZUNG [6] shows.
•
Turn STROM GROB [5] counter clockwise until the display [1] shows the desired maximum output
current.
•
Removing the wire from the terminal to end the short circuit.
•
Connect the load to the terminals [10 & 11] of this device.
•
Do not change the value of the output current as long as the load is connected.
Addition of Output Voltages by Series Connection of multiple Power Supplies:
•
Keep the distance between the connected devices as short as possible.
•
Now connect the terminals + and – of one device crosswise with the terminals – and + of the next
device.
•
Adjust the same value of output current on every one of the connected devices.
•
The output voltage can be adjusted on each device individually. The values of output voltages of all
connected devices are added.
•
The desired load must be connected to the terminal – of the first and to the terminal + of the last power
supply.
