Annex A
EN
Technical Data
EN
Version
EN
Electrical data
EN
Input
EN
Input signal
EN
Switching signal
EN
EN
Current
EN consumption
EN
EN
EN
Output
EN
Minimum load
EN
Maximum load DC 220 V / 0.1 A
EN
EN
EN
EN
EN
Maximum load AC 250 V / 4 A cos φ > 0.7
EN
EN
Max. switching
EN
capacity
EN
Ambient conditions
EN Ambient temperature
Single device
EN
Group assembly
Storage temperature -40 to +80 °C
Relative humidity
(no condensation)
Use at the height of
14
I.S. Relay Module
Series 9172
9172/.0-11-00
Ex i
14 to 30 V
Note the internal resistance of the triggering digital output.
< 16 mA at 12 V
< 11 mA at 24 to 30 V
Digital output with
electronic limitation
requires a minimum
output current of 20 mA.
1 V/1 mA
125 V / 0.25 A
60 V / 0.3 A
30 V / 4 A
for Zone 2 installation
max. 125 V AC / DC
for Zone 2 installation
max. 125 V AC / DC
100 W/100 VA
-20 to +70 °C
-20 to +70 °C
The installation conditions affect the ambient temperature.
Observe the "Cabinet installation guide"
95 %
< 2000 m
9172/.1-11-00
non-Ex i
12 to 31.2 V
< 25 mA at 12 V
< 17 mA at 24 to 31.2 V
–
45 V / 0.5 A
30 V / 4 A
–
30 V / 4 A cos φ > 0.7
–
–
9172/.2-11-00
Ex i
14 to 30 V
< 16 mA at 12 V
< 11 mA at 24 to 30 V
Digital output with
electronic limitation
requires a minimum
output current of 20 mA.
