ASSEMBLY AND STORAGE
Content List
1 No. Top Frame (BLACK)
4 No. Vertical Tubes (RED)
2 No. Base Feet (BLACK)
2 No. Brace (RED)
10 No. Locking Pins
Assembly
1. Connect the two braces (red) with the base feet (black) to form the base.
2. Ensure the holes are aligned and insert the first four locking pins to secure
the base.
3. Insert two of the vertical tubes (red) into the base feet (black) and lock in
place using two more pins.
4. Add the other two vertical tubes (red) to put the Pull Up Mate at full
height, and lock in place using two more pins.
5. Connect the top frame (black) to the vertical tubes (red) and lock in place
using the final two pins.
6. Disassemble in reverse order to assembly and store in a safe place out of
the reach of children.
MAXIMUM USER WEIGHT - 110KG
MAXIMUM USER WEIGHT - 120KG
