General Information - Graf VS-Control flex M Wartungsanleitung

1.

General information

For all work, the relevant accident prevention regulations according to BGV C22 must be observed.
Furthermore, the relevant regulations and standards such as DIN 18300 "Earthworks" and DIN 4124 "Ex-
cavations and trenches" must be observed during installation, assembly and repair.
Whenever work is carried out on the system or system components, the entire system must always be
taken out of operation and secured against unauthorised restart.
2. Technical data
Order No.
Shaft diameter
Dimensions (LxWxH)
Connections
Material
1. General information
If there is a risk of frost or wetness, there is an increased risk of slipping
when entering the system!
GRAF offers an extensive range of accessories, which are all matched to
each other and can be expanded to complete systems. The use of accesso-
ries not approved by GRAF leads to the exclusion of the warranty.
VS-Control flex M
340171
DN 600
900 x 695 x 1815 mm
Inlet:
DN 200
Outlet:
DN 250
100 % polyethylene (PE)
Table 1: Technical data
6 / 8
