INSTALLATIONSANLEITUNG
DGLIMWLC
Aufputz-Leser Edelstahl MIFARE
30-Bit Wiegand Ausgangsformat
Aufbau und Beschreibung des Codes
30-bit Hexadezimal. Das Ausgangsformat ist 30-Bit Wiegand (Signale: DATA1, DATA0 und CLOCK)
Der Datenrahmen besteht aus 30 Bits und ist wie folgt aufgebaut:
1 -
Erste Parität: 1-bit – gerade Parität für die ersten 14 Bits
Ausweiscode: Der Code wird aus 7 halben Bytes gebildet.
Jedes Byte wird von Bit 7 an Bit 0 gesendet.
2 - Zweite Parität: 1 Bit – ungerade Parität für die letzten 12 Bits
Bit 1
Gerade Parität von Bit 2 bis
Bit 15
Beispiel A: Dezimaler Transpondercode ist 689905 (in Hexadezimal: A86F1).
1
0000
Parität 1
0
Der gesendete Code hat in Hexadezimal die Nummer 00A86F1
Beispiel B: der hexadezimale Transpondercode ist 0100166A37
1
0000
Parität 1
0
Der gesendete Code hat das Hexadezimal-Format 0166A37.
Pariteit 1:
«0», wenn die 1. Zahl in Bit 2 bis Bit 15 gerade ist
«1», wenn die 1. Zahl in Bit 2 bis Bit 15 ungerade ist
44-Bit Wiegand Ausgangsformat
44-bit Hexadezimal. Das Ausgangsformat ist 44-Bit Wiegand (Signale: DATA1, DATA0 und CLOCK)
Der Datenrahmen besteht aus 44 Bit und ist wie folgt aufgebaut:
1 - Data: 10-stelliger hexadezimaler Code. Jede hexadezimale Ziffer = 4 Bits, zuerst MSBit.
2 - LRC : 4 bit = oder begrenzt zwischen den Zeichen der Daten, zuerst MSBit.
Bit 1 bis Bit 40
Data MSBit zuerst
Beispiel A: der hexadezimale Transpondercode ist 01001950C3.
0000
0001
0000
0
1
Der Code in 44 Bit Hexadezimal-Format ist: 01001950C3.
5
www.cdvi.de
®
13,56 MHz
Bit 2 tot bit 29
0000
1010
0
A
0001
0110
1
6
0000
0001
0
0
1
Data (28 Bit)
1000
0110
8
6
0110
1010
6
A
Bit 41 bis Bit 44
LRC
1001
0101
9
5
Bit 30
Ungerade Parität von Bit 16 bis
Bit 29
1111
0001
F
1
0011
0111
3
7
0000
1100
0011
0
C
3
DE
0
Parität 2
1
Parität 2
