Key features
•
Compact and energy efficient Power Delivery 3.0 charger
•
Charges compatible devices with USB Power Delivery technology in the shortest
possible time
•
Power your mobile devices with up to 65 Watts via USB Type-C
•
Additional USB Type-A QC 3.0 port with up to 36 Watts
•
Universal compatibility with many notebooks, tablets and smartphones
•
Intelligent chipset automatically recognizes the charging mode
•
Safe use due to protection against overcharging, overvoltage, overheating and
short circuit
Installation
Note: Charging cables are not included.
Check the information on the device to be operated to ensure that the specified maximum
current is applicable.
Connect a USB Type-C
(Type-C
1 / Type-C
®
supported device.
Connect a USB Type-A cable (not included) to the USB Type-A interface (Type-A) of the
IB-PS103-PD and the according interface of your supported device.
Connect the EU or UK plug to a 100-240 V AC compatible power outlet.
Usage
Connection
USB Type-C
1
®
USB Type-C
2
®
USB Type-A
USB Type-C
1 + Type-C
®
USB Type-C
1 + Type-A
®
USB Type-C
2 + Type-A
®
USB Type-C
1 + Type-C
®
+ Type-A
Note: In the event of a short circuit, the output power is less than 5 W and the IB-PS103-PD is
not damaged. After the short circuit is removed, operation is automatically resumed.
Manual IB-PS103-PD
cable (not included) to one of the two USB Type-C
®
2) of the IB-PS103-PD and the USB Type-C
®
Maximum input: AC 100-240 V ~50/60 Hz 1.5 A
5 V@3 A = 15 W; 9 V@3 A = 27 W; 12 V@3 A = 36 W;
15 V@3 A = 45 W; 20 V@3.25 A = 65 W
5 V@3 A = 15 W; 9 V@3 A = 27 W; 12 V@3 A = 36 W;
15 V@3 A = 45 W; 20 V@3.25 A = 65 W
5 V@3 A = 15 W; 9 V@3 A = 27 W; 12 V@3 A = 36 W;
20 V@1.8 A = 36 W
2
30 W + 30 W (Max. 60 W)
®
18 W + 45 W (Max. 63 W)
18 W + 45 W (Max. 63 W)
2
®
30 W+ 18 W + 18 W (Max. 66W)
Power Delivery
®
interfaces
®
interface of your
®
