8.
When the new code has been successfully entered, the same message as at the
beginning appears, but displaying the new code number as shown below. This indicates
the end of the code memorization procedure for this key. The code will remain
memorized even if the power supply is interrupted.
9.
Code selection for the other key positions: Select the left or right arrow keys to move to
other key positions. The display will show which key position is now selected. Start now
the procedure as explained for the first key.
D. Manual selection of the system test
1.
Select the "S" key to see the following message:
2.
The second line indicates that only the "S" and "OK" key can be used. Select "OK" to
start the automatic self-test.
The "S" key is used to change the language of the display and should only be used during
installation. After pressing of the "S" key followed by the "OK" key, the language may be
selected with the right arrow key and then confirmed by selection of the "OK" key.
E.
Withdrawal of keys by customers
Customers simply follow the messages appearing on the display.
F.
Technical Data
Voltage
Current
Fuse extern
Alarm terminals
Operating temperature
Storage temperature
Accepted number of keys
Keypad
Display
Operation
Dialog languages
Height / width / depth
Weight
Sheet metal
Lock
G. Guarantee
12 month from purchasing date (invoice) on function and material. All further liability will
be denied.
Robert Rieffel AG
Widenholzstrasse 8, CH-8304 Wallisellen
info@rieffel.ch,
www.rieffel.ch
Memorize code
No 1: 6220404
Test
S, OK
12 VDC
35 mA
max. 10 A
30 V (AC / DC), 6 A
-10 to 55 °C
-15 to 70 °C
7
16 key, membrane
LCD, lighted, 2x16 characters
guided dialogue
German, English, French,
Italian, Swedish, Suomi
367 / 302 / 122 mm
13.5 kg
3 mm
Cylinder lock KABA with safety rose
Tel. +41 44 877 33 33
