Caliber MCD 264BT Schnellstartanleitung

KEY S Y S TEM
Short press Long press
1 Power Power off
2 R ota r y v o l u m e
3 Menu (system)
4 Panel release
5
6
7
8
9 Mode
10 Display
11 Audio menu
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Panel release
Push this button to release the frontpanel
Eject Push this button to eject the CD out of the unit
Power
Power function to activate or deactivate the unit.
Band Band selection allows you to select different reception bands, f.i. FM1, FM2 and FM3
Loud Long press to reinforce the bass output
AF
AF stands for Alternative frequencies; the tuner will return to alternative frequencies whenever the reception signal is getting worse
TA TA stands for Traffic announcement which means that it will give you information about the traffic (if broadcasted) no matter what mode you are in (CD,USB, etc.) it will
automatically interrupt the cd and give the information, after that it automatically switches back to the selected mode
REG
REG stands for Regional program operation. Long press REG will allow traffic announcement from strong stations to come through. Long press REG again will allow all
received traffic announcement to interupt CD pla y or radio listenin g
PTY The PTY function allows you to search for stations with a particular program type like NEWS group and POP group both of these groups are divided in different
subjects.Rotate the volume control to select different PTY as follows:
NEWS -> AFFAIRS -> INFO -> SPORT-> EDUCATE -> DRAMA -> CULTURE -> SCIENCE -> VARIED -> POP M -> ROCK M -> EASY M -> LIGHT M -> CLASSICS ->
OTHER M -> WEATHER -> FINANCE-> CHILDREN -> SOCIAL -> RELIGION -> PHONE IN -> TRAVEL -> LEISURE -> JAZZ -> COUNTRY -> NATION M -> OLDIES ->
FOLK M -> DOCUMENT -> TEST -> ALARM -> NEWS
Seek up/down
Short press to move to the next station automatically
Tune up/down Long press to move the radio frequency number up/down step by step.
Menu (system) Hold button for 2 seconds to open the menu. Press repeatedly to view menu items TA - PI - Retune - MASK - Beep
Audio menu
The Audio menu button gives you the possibility to adjust your sound system with the following options Bass, Treble, Balance and Fader. These options can be used to
fine tune your sound
Equalizer The Equalizer button allows you to select your desired audio mode. Press repeatedly to view modes FLAT - CLASSICS - POP M - ROCK M - DSP OFF
Mode The mode button allows you to go from one source (f.i. CD) to another source (f.i. Tuner) by pushing the button as many times as needed
AMS (AS) AS stands for Autostore; in tuner mode it will automatically store the 6 strongest stations (M1-M6). Note: all previous stored stations are lost
AMS (PS) PS stands for Preset stations this means that when you push this button in tuner mode it will automatically switches to the first preset (M1) if you push again it will go to
the next and so on
Rotary volume
This knob allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears
M1-M6 These are the preset stations where you can store your favorite radio stations if in tuner mode
Pause/Play
This button allows you in CD, USB or SD mode to play or to pause the music
Scan Scan will play 10 seconds of each song on the CD, USB or SD. If the preferred song is playing, push again and it will play that song
Repeat Repeat will play a selected song or album continuously. Available in CD, USB and SD mode
Shuffle Shuffle will play all the songs random. Available in CD, USB and SD mode
Track down/up In MP3 mode press this button to go up or down one track
Fast forward/backward
Long press to fast forward to the CD, USB or SD
3,5mm AUX in Jack To connect an external audio system
USB input When inserting a USB stick the unit will switch to USB mode. (Max 1000 tracks)
SD card input Remove the frontpanel to insert SD card. When inserting a SD card the unit will switch to SD mode. (Max 2GB card, max 1000 tracks)
Reset ( behind p anel ) Use a non-metallic p ointed ob j ect to p ress and hold the reset button for 5 seconds. The unit will be set to factor y default
BLUETOOTH O p en Bluetooth menu b y p ressin g and holdin g "Menu" button
Pairing
Activate BlueTooth on your mobile phone, and search for available devices. Select "Caliber-BT", password "0000". If succesfull "Connected" is displayed, if not "Pairing
Fail!" will be displayed for 3 seconds. The unit will go back to the previous mode.
Reconnect The unit will normally auto-reconnect.
Reject incoming call Press (BAND) button if you not wish to answer the call, and return to normal playing mode.
Transfer To audio transfer from headunit back to the mobile p hone. Lon g p ress the Transfer ( MODE ) button to transfer the audio back to y our mobile
T U NER
Short press Long press Short press
Eject
Mode Mode
AMS (PS) AMS (AS)
Band ENTER
Seek down Tune down
Track down
Seek up Tune up Track up
PTY
AF REG
TA
M1 Memory 1 Play/Pause
M2 Memory 2 Scan
M3 Memory 3 Repeat
M4 Memory 4 Shuffle
M5 Memory 5 down -10
M6 Memory 6 up +10
Descri p tion of the functions
Note! Do not o p erate the unit while drivin g .
C D / MP 3/ WMA BT A ud i o
Long press
Di sc s l ot
L C D Di sp l ay
US B po r t
Fast backward
Fast forward
File/track up
File/track down Fast backward
3,5 mm A U X in Jac k
MCD 264BT
English
BL U ET OO TH
Short press
Answer incoming call Transfer phone
conversation back
m ob il e p h o n e
#9
Pause/play #0
Reject incoming call
/End call
*
#
#8
#7
#1
#2
Fast forward #3
#4
#5
#6
Long press
to
