Operating Instructions
The mEssfix compact is a measuring device with analogue display 1 for taking measurements on
construction sites and in interior outfitting.
Ref.-No.
Measuring range
Weight
Calibration class
Clean the telescopic elements before sliding them in.
The telescopic rule is not suitable for measuring in liquids.
The telescopic elements may not be oiled.
Do not touch electrical lines with the mEssfix compact!
Severe danger of electric shock.
Handle the mEssfix compact like a measuring tool. The built-in horizontal spirit level 3 and the
vertical spirit level 2 are used for horizontal and vertical alignment of the telescopic rule during
measuring. Use the protective case for transport and storage.
Regularly check the permissible measuring deviation for calibration class II by comparing with a
rule and check the analogue display 1 when slid in.
Measuring deviation, max.
Analogue display when slid
in (A)
We reserve the right to make technical changes.
Operating instructions mEssfix compact
F380211
F380211-600
0.60 m – 3,04 m
0.9 kg
II
< 1 m (±0.5 mm); < 2 m (±0.7 mm); < 3 m (±0.9 mm);
< 4 m (±1.1 mm); < 5 m (±1.3 mm)
59.3 cm – 59.5 cm
F580211
F580211-600
0.91 m – 5.01 m
1.4 kg
II
90.8 cm – 91.0 cm
