axing EOC 30-01 Installationsset-Anleitung Seite 3

 Observe the safety instructions supplied with the device!
They are also available at the following Internet address:
https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf
 Use the device only as described in these operating instructions and in
particular in accordance with the state of the art.
If the device is used for other purposes, no warranty will be assumed!
Commission regulation (EU) 2019/1782
External plug-in power supply
Manufacturer's name or trademark Channel Well Technology Co Ltd
commercial registration number and 222 Sec 2 Nankan Rd, Lujhu Township Taoyuan
address Hsien, 33855 Taiwan | 84573516
Model identifier
Input voltage
Input AC frequency
Output voltage
Output current
Output power
Average active efficiency
Load condition 1 – 100 % ± 2 %
Load condition 2 – 75 % ± 2 %
Load condition 3 – 50 % ± 2 %
Load condition 4 – 25 % ± 2 %
Efficiency at low load (10 %)
No-load power consumption
State of the art 2021-03-22
Technical improvements, changes in design, printing- and other errors reserved.
Technical data:
Type
Frequency range
Connectors (G.hn | TV)
Frequency range transmission
Frequency range TV bypass
Maximum allowed attenuation
in coaxial network
EoC
Standard
Net data rate (PHY)
Encryption
Max. number of devices
in EoC network
Interfaces
Ethernet connectors (LAN)
Ethernet standards
General
Operating voltage
Power consumption
Operating voltage over Coax
Operating voltage over LAN
(PoE)
Operating temperature range
Operating humidity (non-con-
densing)
Dimensions (W × H × D) appr.
Weight
External accessories
Switching power supply
EOC 30-01/-21
General
Comments
2AAJ012F EU
100...240 V
50...60 Hz
12,0 V
1,0 A
12,0 W
82,5 %
83,7 %
Herewith AXING AG declares that the marked products comply with the valid
84,0 % guidelines.
83,4 %
WEEE Nr. DE26869279 | Electrical and electronic components must not be
75,7 %
disposed of as residual waste, it must be disposed of separately.
0,04 W
Manufacturer
AXING AG
Gewerbehaus Moskau
8262 Ramsen
EOC 30-01 EOC 30-21
5...1800 MHz
-
5...204 MHz
258...1800 MHz
77 dB
ITU-T G.9960 G.hn over Coax
1800 Mbps*
AES 128 Bit
16 32
2 × RJ 45
IEEE 802.3u 100BaseT Fast Ethernet
IEEE 802.3ab 1000BaseT Gigabit Ethernet
IEEE 802.3az Energy Efficiency Ethernet
12 VDC
<5 W <7 W
60 VAC +/- 20%
37...57 V
-10°C...55°C
10...95%
178 x 136 x 35 mm
0,375 kg 0,380 kg
100...240 V~/50/60Hz | 12 V=/1 A
* The data rate indicates the data throughput between
the EoC devices. For technical reasons, a maximum of
1000 Mbps is available at each Ethernet interface.
EEA contact address
Bechler GmbH
Am Rebberg 44
78239 Rielasingen
EOC 30-01 | EOC 30-21
premium-line
Ethernet over Coax
Master | Dual Master
Quick start guide
