3 | Safety information
Only use the device if it is completely free of faults, and with safety
and awareness in mind.
If warnings or symbols are attached to the luminaire, they must not
be removed.

4 | Assembly/Mounting

Check the LED luminaire before installation to ensure it is complete and shows no
signs of damage. Do not use the luminaire or accessories if they are damaged, as
there is a risk of injury.
The LED luminaire comes fully assembled. The LED luminaire is attached via the srew-
on base and four srews M6.
Optional there is follow accessories for this luminaire:
Permanent Holding Magnet CENALED screw-on base
Table clamp CENALED screw-on base
Wall angle bracket CENALED screw-on base
When mounting the luminaire, make sure that the luminaire is
fastened securely and stably. If the luminaire falls down, its weight
poses a risk of injury!

5 | Connection

CENALED SPOT DC - item numbers 121012-0x:
The direct current LED luminaire has a sensor cable of three meters, PVC oil resistent,
and two open cable ends for a direct connection to a machine control for example. For
further connection options, like cables, plugs or materials you can find in the accesso-
ries of LED2WORK.
10 | BA CENALED . BA 04/2021
4x Befestigungsbohrungen für M6
Item no.
220500-01
220500-02
220500-03
