WARNING!
When using R27 INCAR trolley on a wall or ceiling mounted rail not properly horizontal installed,
pay attention because in the event of a fall the trolley will slide without impediments.
Using removable or openable endstop:
In case of using removable or openable endstop
of the rail, always check that they are correctly mounted
as described in the R27 Rail and R27 LongSpan
Instruction Manual.
If using IN1642.CLEAR removable
endstop, always be sure the pinstop is
inserted into one of the stop holes in the
rail. The bottom of the knob must be
nearly flush with the body
of the endstop.
WARNING!
Always be sure the pinstop is securely
fastened to a pinstop hole in the rail.
Failure to seat in a pinstop hole
can result in a fall which could result in
severe injury or death.
If using INSTOP-OPEN.LS openable endstop,
always be sure that fixing clip is correctly positioned.
WARNING!
Always be sure the fixing clip
is correctly positioned.
Failure to use the fixing clip can result
in a fall which could result in severe
injury or death.
26/02/21
IN1642.CLEAR
endstop
ENGLISH
CORRECT
INCORRECT
