Supply (fig. 0)
- UV-C 36W lamp provided with power cord L=2000; nominal cross-section: 3x0.75 mm
- Bracket and accessories for wall or ceiling installation: 1 bracket + 1 fixing insert, 2 M6x10 screws; 2 M6 washers;
2 M6x10 grub screws; 6 cable ties).

Optional accessories

PIR SYSTEM (13049)
- Presence detector -
C PIR (cod. 12998)
- Presence detector -
KIT FN1 system (21495)
- Kit for ceiling horizontal
installation -
KIT FN2 SYSTEM (21496)
- Kit for ceiling horizontal
installation -
MTB SYSTEM (cod. 21497)
- kit for wall horizontal installation -
STB SYSTEM (cod. 21498)
- Vertical ceiling installation kit for 1,
2 or 3 products -
KIT SR SYSTEM (cod. 21460)
- Kit for installation of two lamps in
series-
2
(outer Ø = 7 mm)
See Connection
Diagram
Fig. B
See Connection
Diagram
Fig. C
See Connection
Diagram Fig. D
