wohner CAPUS Panel Bedienungsanleitung Seite 3

1. Mounting plate installation
3.Terminal cover
3
3mm
1,5Nm
2. Connection of conductors
S32-160
4x M6x16
2Nm
5mm
1.1
Further information about the connection of cables available on www.woehner.com
4. External handle and Red-Yellow handle
3.1
Cable lugs
Bars
DIN 46234
IEC: stranded, solid, flexible
15x3
50mm²- M8
UL: stranded, solid
2
h
h
4
5
Cables
M6x15
7Nm
10mm
2.1
0,8x3,5
1
4.1
4.2
