KikkaBoo ALVI Gebrauchsanweisung Seite 6

WARNING
READ THE INSTRUCTIONS CAREFULLY BEFORE USE AND SAVE THEM FOR FUTURE REFERENCE! THE CHILD CAN BE HURT IF YOU DO NOT OBSERVE THESE
INSTRUCTIONS!
• The instruction can be kept in the reserved place of the car seat within the usage period.
• Do not use this child seat in the home. It has not been designed for home use and should only be used in your car
• Be sure that children are not left in their child restraint system unattended.
• The child restraint system should be changed when it has been subject to violent stresses in an accident.
• Any straps holding the restraint to the vehicle should be tight; Restraining the child should be adjusted according to the child's body, and should not
be twisted.
• Any lap strap should be worn low down, so that the pelvis is firmly engaged, shall be stressed.
• Be sure any luggage or other objects liable to cause injuries in the event of a collision shall be properly secured.
• The rigid items and plastic parts of a child restraint shall be so located and installed that they are not liable, during everyday use of the vehicle, to
become trapped by a movable seat or in a door of the vehicle.
• It is danger to make any alterations or additions to the device without the approval of the Type Approval Authority, and it is also danger not following
closely the installation instructions.
• It is extremely dangerous to use any load bearing contact points other than those described in the instructions and marked in the child restraint.
• The child restraint shall not be used without the cover; The seat cover should not be replaced with any other than the one recommended by the
manufacturer.
• The child should be taken out from the car seat when it is being moved or
adjusted.(except adjusting the headrest)
• The seat should be kept away from sunlight if the seat is not provided with a textile, otherwise it may be too hot for the child's skin.
• Please do not buy the second hand safety car seat. Because you may not know the using history of the car seat. It may have been in an accident or lack
some parts.
I. PARTS:
1. Handle; 2. Handle adjuster; 3. Adjustable straps; 4. Shoulder straps adjuster; 5. Cover; 6. Comfort pad; 7. Buckle pad; 8. Buckle; 9. Shoulder pad; 10.
Strap; 11. Headrest pad; 12. Fixed bar; 13. Lap belt hook;
II. INSTALLATION LOCATION AND ADJUSTMENT OF CHILD SEAT
2.1. THE RIGHT FITTING POSITION IN THE CAR
Only suitable use in the listed vehicles fitted with 3 point with retractor safety-belts, approved to ECE Regulation No.16 or other
equivalent standards.
2.2. ADJUST THE HEIGHT OF HARNESS STRAPS
Always check that the shoulder are at the correct height for your child. The child`s shoulder should always be below the slot for the harness straps. The
right fitting is showns on the picture.
2.3. ADJUST THE HEIGHT OF SHOULDER RESTRAINT
Loosen the shoulder straps, open the buckle. Pull out the buckle tongues from the chest pad and the slots on the cover and the shell, then thread them
into the corresponding belt slots. Ensure that both of the shoulder belt go through slots at the same height, and not twisted.
2.4. OPERATION OF BUCKLE
Loosen the harness, open the buckle, and place them down side ways. Seat your child in the child car seat. Place both shoulder straps over your child's
shoulders.
NOTE: Baby below 5kg,using comfort pad and headrest pad. Baby above 5 kg, only using headrest pad.
Put the two metal sections of the buckle connectors together. Slot the two buckle connectors into the slot in the top of the buckle until they "click" into
place. Check the harness is correctly locked by pulling the shoulder straps upwards.
2.5.TIGHTEN AND LOOSEN THE HARNESS RESTRAINT
Pull the adjustment straps until the harness straps are totally tight. The shoulder restraint shall be adjusted as tightly as possible without causing
discomfort to your child. Check whether the straps are adjusted tightly enough and not twisted when the child is placed in the seat. Be sure the distance
between the shoulder straps and shoulder is less than 1 cm. The lab strap shall be worn low down, so that the pelvis is firmly engaged. The loose straps
are very dangerous for the child.
Find the right position of harness strap adjuster. Keep pressing down the harness straps adjuster by one hand, meanwhile grip two shoulder straps and
pull them towards you by the other hand. With the operation mentioned above, you can loosen the harness restraint and adjust as you required.
