OPERATION GUIDE
1. Put the micro USB port into the power input of the desk lamp
FIG 1
2. Refer to the functions of each button in previous page (Outline) to use the lamp. Short
press is required to adjust the functions except that brightness increase and decrease need
long press.
3. When using the wireless charging function, place phones with Qi receiver onto the
wireless charging area. At this time, the wireless charging indicator turns on and flickers
to indicate that wireless charging is ON. The indicator turns off after the phone is
removed.
4. To charge a digital device, use a piece of charging cable to connect the USB output port of
desk lamp with the charging port of the device.
FIG 3
FIG 2
USB Output Port
5V/3A Input Port
ENGLISH
