STARTER
FOR LED TUBES
DUMMY STARTER
INCLUDED
TECHNICAL DATA:
Model
VT-061
Wa s
10
Lumens
850
CRI
>80
PF
>0.5
BeamAngle
160°
Body Type
Plas c
Holder
G13
Long Life
30,000 Hours
On/O Cycles
>15000
Dimension
600x27.9mm
Input Power AC:220-240V,50Hz AC:220-240V,50Hz AC:220-240V,50Hz AC:220-240V,50Hz AC:220-240V,50Hz AC:220-240V,50Hz
This marking indicates that this
product should not be disposed
of with other household wastes.
LED Lamps suitable for 50Hz
operation
LED Lamps to be used in dry conditions
or in a luminaire that provides protection
5
*
WARRANTY
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE,
INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTALLATION INSTRUCTION
T8 LED Tubes
VT-121
VT-151
18
1700
2000
>80
>80
>0.5
>0.5
160°
160°
Plas c
Plas c
G13
G13
30,000 Hours
30,000 Hours
>15000
>15000
1200x27.9mm
1500x27.9mm
LED replacement starter
(Included in the packaging)
VT-062
22
10
1100
>80
>0.5
160°
Plas c
G13
30,000 Hours
>15000
600x27.9mm
Caution, risk of electric shock.
LED Tubes are NOT suitable for
dimming
LED Tubes not suitable for
EL
emergency operations
WEEE Number: 80133970
VT-122
VT-152
18
22
2250
3000
>80
>80
>0.5
>0.5
160°
160°
Plas c
Plas c
G13
G13
30,000 Hours
30,000 Hours
>15000
>15000
1200x27.9mm
1500x27.9mm
