Installing your DigiSender® XDHDMI

Step 4 - Install the Receiver

The Receiver will pick up the signals being sent by your Transmitter and output them to a connected
TV.
1.
AV OUT HDMI OUT
Use one of the included HDMI cables and connect
it to the socket labelled 'HDMI OUT' on the back of
the DigiSender® Receiver and the HDMI input on
your receiving TV.
Please read the instructions carefully prior to installation
DGXDSDV112 - DigiSender® XDHDMI - Single Input HDMI AV Sender System
PAIR
AV OUT
2.
HDMI OUT
ANT
Connect the Power Supply Unit (PSU) to the socket
labelled 'PSU' on the back of the DigiSender® Re-
ceiver and plug it into an available mains socket.
The Power Indicator will light up Red to indicate that
the unit is in Standby Mode.
ENGLISH (EN)
ANT
Page 07
