PAPER ROLL REPLACEMENT

1. Lift the paper holder up. (Fig. 1)
2. Fold the leading edge of the paper roll 3 to 5 cm.
(Do not fold it slantwise.) (Fig. 2)
3. Insert the paper roll from the left side of the paper
holder and make sure the paper roll is set in the
proper direction (with the paper feeding from the
bottom). (Fig. 3)
4. Insert the leading edge of the paper into the
opening directly behind the print mechanism.
(Fig. 4)
5. Press the paper feed key and feed the paper
under the edge of the paper cutter. (Fig. 5)
Paper holder
Fig. 1
Downloaded from:
3 cm – 5 cm
(1-3/16" to
1-31/32")
Fig. 2
http://www.usersmanualguide.com/
Fig. 4
DO NOT PULL PAPER BACKWARDS AS THIS
M AY C A U S E D A M A G E T O P R I N T I N G
MECHANISM.
9
Fig. 3
Paper cutter
Fig. 5
