THE FOLLOWING PARTS ARE INCLUDED IN THE SCOPE OF DELIVERY:
1.
Symbol Pro loudspeakers (2 pcs.)
2.
Wall bracket (2 pcs.)
3.
Wall bracket base plate (2 pcs.)
4.
M5 x 40 mm hexagon socket screw (4 pcs.)
5.
Washer (4 pcs.)
6.
M5 nut (4 pcs.)
7.
5 x 50 mm fastening screw (6 pcs.)
8.
8 x 40 mm plug (6 pcs.)
9.
Tab washer (2 pcs.)
10. M5 x 7 mm hexagon socket screw (4 pcs.)
11. Lock washer (2 pcs.)
12. Safety cable (2 pcs.)
13. 4 mm spanner
For safety reasons, Items 9 and 12 must be fitted as shown in Fig. 2.
To ensure stability, the supplied rubber feet should be attached to the bottom of the box
(four per box) if the loudspeakers are used without wall brackets.
The Symbol Pro loudspeakers are widely resistant to moisture so that they may also be
used outdoors and in damp rooms. Observe the following points in order to ensure perfect
functioning over the long-term:
•
Do not expose to direct sunlight and permanent humidity (e.g. rain) for extended
periods of time.
•
Only use at temperatures ranging between –5 °C and +50 °C.
CONNECTING YOUR MAGNAT SYMBOL PRO SPEAKERS
Please always use good quality loudspeaker connection cable from an audio dealer. To
prevent impairment of sound quality we recommend cables with cross-sections of at least
2.5 mm² for lengths up to 3 m and at least 4 mm² for lengths above 3 m.
Always turn off the amplifier or receiver before connecting or disconnecting loudspeaker
cables. Place the loudspeakers in their planned positions and cut the cables to the right
length (see Positioning Your Magnat Symbol Pro Speakers above). The cables for both
channels should always be exactly the same length.
GB
9
