4
Technical specifications
Frequency range
VSWR
Antenna gain
Impedance
Polarization
Radiation angle
Connector
Dimensions
Weight
Wind speed
Crosstalk attenuation
between the antenna
connectors
Front to back ratio
Storage temperature
Operating temperature
Degree of protection
RoHS 2002/95/EC
4.9 to 5.9 GHz
< 2.0
14 dBi
50 Ω
Dual, linear, vertical-horizontal
30° horizontal and vertical
2x N connector, female
283 x 100 x 40 mm
0.52 kg
200 km/h
> 19 dB
> 35 dB
-40 °C to +70 °C
-40 °C to +70 °C
IP66
Met
EMC protection
Fire prevention
Silicone-free
Material antenna foot
Material outer casing
5
Dimensional drawing
(dimensions in millimeters)
6
Field diagrams
Horizontal 5.6 GHz
Vertical 5.6 GHz
EN 50155
(For railway applications: In the
train)
EN 50121-4
(For railway applications: on the
track)
EN 45545-2
Yes
Aluminum
ASA
