PowerLan 200
4 Configuration
Start the Utility:
To start the utility, double click the PowerPacket Utility icon on your desktop.
Main Screen
The Main screen provides a list of all PowerLan devices connected to the
computer where the utility is running.
The top panel shows all local PowerLan devices connected to the computer's
NIC (Network Interface Card). In most cases, only one device will be seen. If
more then one device is connected, the user can select the device and click the
Connect button. The status area above the button indicates that your PC is
connected.
The lower panel displays all the PowerLan devices, discovered on the current
logical network (remote devices). Displayed above this panel is the number of
remote devices found, the type of logical network (Public or Private), and a
message area that reports the connectivity and scan status.
