OCD5/MCD5-1999 / OWD5/MWD5-1999
3. Click the cover into place by applying light, even pressure.
Warning! Do not apply pressure to the corners of the display
cover or to the display itself.
DO NOT open the thermostat by releasing the four fixing clips on
the back.
Fig. 8 - Operating the thermostat
There is an ON/OFF switch on the left side of the thermostat: up is
ON - down is OFF.
The resistive touchscreen requires a soft tap with your fingertip to
register the touch.
Installer Wizzard:
The first time the thermostat is connected, push the power slide
button to On "I" The Installer Wizard on the touchscreen will guide
you through the set up of:
1. Region
2. Language
3. Date
4. Time
5. Floor Type
Programming
See user manual.
http://www.ojelectronics.com/OCD5
Fig. 9 - Troubleshooting
If the sensor is disconnected or short-circuited, the heating system
is switched off. The sensor can be checked against the resistance
table.
10
http://www.ojelectronics.com/OWD5
