• Four channel power amplifi er
• 150 x4 watts into 2 ohms load
• 75 x4watts into 4 ohms load
• High effi ciency TO3PL transistor on amplifi er stage
• Variable Low-High-Band pass x-over on rear section at 18/12dB/oct
• Variable High pass x-over on front section at 12dB/oct
• In/Out mode selector (2/4 ch In)(ST/Dual mono Out)
• Adjustable x-over from 30Hz to 600Hz
• EBC external bass control on rear section
• Pre-amplifi ed output with High pass crossover option
• PWM Mos-Fet power supply
• 20sq.mm power terminals
RMS Power at 4 ohm Stereo load at 14,4 volts
RMS Power at 2 ohm Stereo load at 14,4 volts
RMS Power at 4 ohm Bridged load at 14,4 volts
THD (total Harmonic Distortion)
Frequency response (+0/-1 dB)
Signal to noise ratio
Low Input sensitivity
High Input sensitivity
Input impedance
Crossover type
Crossover frequency & fi lter slop (High-pass)
Crossover frequency & fi lter slop (Low-pass)
Line Output
Dimension (w * h * d) mm
10
Features
Technical data
75 x 4 watts
150 x 4 watts
300 x 2 watts
< 0,1%
10 - 30,000Hz
> 100dB
200-8,000mV
1-10V
22k/100 ohm
Variable
30 to 600Hz -12dB/octave
30 to 600Hz -18dB/octave
1-1 (with High pass)
250 x 55 x 360
