The power distributor is the item that distributes and protects the very low voltage lines (12 VDC)
of the caravan, such as the lines for lights, pump, etc. It has a connection with a control panel with
which it displays the status of the outputs and inputs of the following device.
Fuses
Fuse Code Cut-off Power
F0 NOT USED
F1
F2
F3
F4
F5
F6
F7
F8
F9 NOT USED
Detail of connectors
Connector Name
CT1 Service Battery
CT2 Engine Battery
CT3 Lights
CT4 Fridge
CT5
CT6
CT7
CT8 Step
CT9
CT10
J1 Services
NOT USED
20 A Fridge
15 A
15 A Lights 2
15 A Lights 1
5 A Outside Light
10 A Services
15 A
10 A Pump
NOT USED
Contacts
1 - Positive
2 – Positive
1 - Negative
2 – D+ Signal
1 - Negative
2 – Negative
1 - Negative
2 – Positive Gas lighting
1 – Positive | D+
1 – Positive
1 – Negative
1– D+
2 – **
1 – Services Positive
1 – Services Negative
1– Serv. Positive
2 – Serv. Positive
3 – Serv. Positive
4 – D+
Power Distributor V.05
User
NOT USED
Conditioned by switching on the engine
and by the fact that engine battery voltage
must be over 13.4V. If the voltage falls
below 12.5 it releases
Aux Direct to the Services Battery
Controlled by the control panel
Controlled by the control panel
Controlled by the control panel and
switching off automatically with the
engine on
Direct to the Services Battery
Step Direct to the Services Battery
Controlled by the control panel
NOT USED
5 – Earth
6 – Outside light
7– Earth
8 – Earth
2
N.3, N.4,N.5
Logic
3 – AC Sense
4 – Negative
3 – Positive
4 – Positive
3 – Positive
4 – Positive
3 – Positive Fridge
4 – Positive Fridge | D+
3 – Positive
4 – Negative
9 – Earth
10 – Pump
11 – Earth
12 – Earth
