Technical Specifications
Pushbuttons and warning lights
SW1: General lights pushbutton and warning light
SW2: Tank test pushbutton pressing the button for 10 sec the panel shows the status of the tanks
SW3: Battery test pushbutton pressing the button for 10 sec the panel shows the status of the
batteries
SW4: Outside light pushbutton and warning light
SW4: Pump pushbutton and warning light
Displays
S1 fresh water tank
S2,S3 recovery tanks
The meaning of the led bar for the tanks is as follows:
Level Display
Reserve Red led on
1/3 ~ 2/3 Green led 1/3 on
2/3 ~ 3/3 Green led 2/3 on
Full Green led 3/3 on
B2 services battery voltage display bar
B1 engine battery voltage display bar
The meaning of the led bar for the batteries is as follows:
Battery voltage in Volts
< 10
10 ~ 11
11 ~ 12
12 ~ 12,6
>12
The green led with the plug symbol is on when the outside power supply is used
The red led with the fuse symbol is on when at least one distributor fuse has blown.
Automatic devices
When the services battery voltage falls below 10V the corresponding red led flashes and after a few
seconds the lights and pump are deactivated.
Size and weight
Size (LxWxH) 21x12x1.5 cm Weight approx. 130 gr/pcs
Display
Red led flashing
Red led on
Green led 1/3 on
Green led 2/3 on
Green led 3/3 on
