Battery Charger 216W AL-C20 N.1
Technical Specifications
Input: 88~132 / 176~264 switch selectable
Rated current 20A@12V
Max. current: 135% of rated current
Maintenance voltage 13.8V
Remote signal to indicate presence of mains voltage
Protections
Short circuit, overload, over voltage, high temperature
Connections
Input: AC Outlet (115 – 230 VAC) AMP Mate-M-Lok 3x1 Connector
Output: Faston 3-Way Red (+12), Black (Earth), Grey (Mains presence) Connector
Caution
Keep the device in a dry place.
Disconnect the low voltage mains supply (115/230VAC) to carry out maintenance work
Standards
EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4, ENV50204
Size and weight
(LxWxH) 16x8x16 cm 1.4 Kg/pcs
