C
c1
x2
Sistemi di fissaggio
non inclusi
Fixing system
not included
c4
SERRARE PER GARANTIRE LA TENUTA
TIGHTEN TO ENSURE TIGHTNESS
TARGETTI SANKEY S.p.A. Via Pratese n°164 Florence Italy
c2
c3
c4
20
288
230V
DALI
USARE CAVO 5G1mm² MAX
H07RN-F Ø7,5mm÷12,5mm MAX -
O EQUIVALENTE
USE CABLE 5G1mm² MAX
H07RN-F Ø7,5mm÷12,5mm MAX
OR EQUIVALENT
EL
USARE CAVO 3G1mm² MAX
H07RN-F Ø7,5mm÷12,5mm MAX
O EQUIVALENTE
USE CABLE 3G1mm² MAX
H07RN-F Ø7,5mm÷12,5mm MAX
OR EQUIVALENT
24Vdc
USARE CAVO 2x1mm² MAX
H05RN-F Ø7,5mm÷12.5mm MAX
O EQUIVALENTE
USE CABLE 2x1mm² MAX
H05RN-F Ø7,5mm÷12,5mm MAX
O EQUIVALENT
www.targetti.com
5,5
- 4 -
