LOGICO
1 T X X X X
+35°C
-25°C
L'apparecchio non deve, in alcuna
circostanza, essere coperto con
materiale isolante o similare.
The luminaire shall, under no
circumstances, be covered with
insulating matting or similar material.
RG1 secondo norma IEC/TR 62778:2014 / RG1 in accordance with IEC/TR 62778:2014
RG1 selon la norme IEC/TR 62778:2014 / RG1 nach der norm IEC/TR 62778:2014
RG1 enlight IEC/TR 62778:2014 / RG1 volgens IEC/TR 62778:2014
TARGETTI SANKEY S.p.A. Via Pratese n°164 Florence Italy
E L Electronic
D A
DALI Dimmable
220-240V
50/60Hz
RG1 de acordo com norma IEC/TR 62778:2014
12W Sorgente Led / Led source
14W Apparecchio / Fixture
COD. 1T6015 / 1T6016 / 1T6807 / 1T6808
COD. 1T6809 / 1T6810
16W Sorgente Led / Led source
18W Apparecchio / Fixture
COD. 1T5465 / 1T5466
24W Sorgente Led / Led source
27W Apparecchio / Fixture
COD. 1T5431 / 1T5432 / 1T5435 / 1T5436
COD. 1T5437 / 1T5438 / 1T5461 / 1T5462
COD. 1T5467 / 1T5468 / 1T5475 / 1T5476
COD. 1T6017 / 1T6018 / 1T6811 / 1T6812
36W Sorgente Led / Led source
40W Apparecchio / Fixture
COD. 1T5441 / 1T5442 / 1T5445 / 1T5446
COD. 1T5447 / 1T5448 / 1T5471 / 1T5472
COD. 1T5477 / 1T5478
48W Sorgente Led / Led source
54W Apparecchio / Fixture
COD. 1T5433 / 1T5434 / 1T5439 / 1T5440
COD. 1T5463 / 1T5464 / 1T5469 / 1T5470
COD. 1T5485 / 1T5486
72W Sorgente Led / Led source
81W Apparecchio / Fixture
COD. 1T5443 / 1T5444 / 1T5449 / 1T5450
COD. 1T5451 / 1T5452 / 1T5455 / 1T5456
COD. 1T5457 / 1T5458 / 1T5473 / 1T5474
COD. 1T5479 / 1T5480 / 1T5481 / 1T5482
COD. 1T5487 / 1T5488
144W Sorgente Led / Led source
163W Apparecchio / Fixture
COD. 1T5453 / 1T5454 / 1T5459 / 1T5460
COD. 1T5483 / 1T5484 / 1T5489 / 1T5490
In caso di dubbi sulla simbologia,
riferirsi al catalogo o al sito web.
If in doubt about the symbols refer
to catalog or website
misure in (mm) ; measures (mm)
cod. 2CL6CS00
www.targetti.com
- 1 -
