1.1 - PRELIMINARY CHECKS AND IDENTIFICATION OF THE TYPE TO BE USED

Before installing DIMO700 please check the following basic points:
• The door must be suitable to be automated (check the door operation manual and directions). The door structure itself must be stout
and appropriate to be automated.
• Fix the engine steadily and using suitable material.
• Check the door to be provided with anti-fall system (independent of the suspension system)
• The door must be functional and safe.
• The door must open and close easily without any friction.
• The door must be properly balanced both before and after its automation: stopping the door in any position, it must not move (carry out
a balance weight adjustment, if necessary).
1 - Actuator DIMO 700
2 - Photocells (not included)
3 - Power socket
- 15 -
wire 2 x 0.75 mm2
wire 4 x 0,5 mm2 (RX)
wire 2 x 0,5 mm2 (TX)
-
