NOTE
After a rotation process has been stopped, the next rotation process will start over
again anew with the displayed parameters.
The turntable must under no circumstances be turned by force – this can
damage the internal mechanics.
When using the pan head, make sure you are keeping to permitted values for maxi-
mum load-bearing capacity (see section 12. Technical Specifications)
When using the pan head, make sure the mounted equipment is placed as centrally
as possible.

7. Maintaining the device

1. Switch off the device [5]. See section 6.1.
2. Remove the camera/equipment and possibly, the USB cable
3. Clean the device if necessary See section 8.2.
4. Lay the device in its original packaging and store as specified in the technical
specifications. See section 12.

8. Troubleshooting

Problem Cause
The device is Batteries not sufficiently
switched on, but charged
does not show any
function.
Device defective
Device has fallen/ Fall (also risk of battery
been dropped damage)
8.1 Check and service the device at regular intervals
In case of damage have the device checked and repaired by a professional
electrician.
8.2 Cleaning the device
WARNING
Electric shock hazard / fire risk (battery)
Use only the specified cleaning agents.
Do not bring the device into contact with moisture or water.
22
Remedy
Charge / replace batteries
Contact the manufacturer
Have the device checked by an
electrician
Cleaning
Device part Cleaning
Housing Remove light and stubborn dirt with a dry micro-fibre cloth

9. Accessories and options

You find the best accessories for your device in our web shop:
www.foto-walser.de.

10. Waste disposal and protection of the environment

Dispose of the device at a legally specified collection point, such as with the
manufacturer, electronics brands or at a local disposal depot. This service is free
of charge.

11. Reference to the declaration of conformity

„Hereby, WALSER GmbH & Co. KG declares that the device is in agreement with
the basic requirements and the other relevant provisions of Directive 2014/53/EU".
The declaration of conformity can be requested at the following address:
info@walser.de.
12. Technical Specifications
Working current:
Standby current
Power supply:
USB micro jack:
(for USB power banks and USB mains adapters)
Max. load capacity for
horizontal pans:
Max. load capacity for verti-
cal pans:
Product weight:
Connection: 3/8 (bottom, 1/4" adapter incl.) & 1/4 Inch (turntable)
Size:
200 mA
10 mA
AA 4x 1,5 V = 6 V
(batteries or rechargeable batteries)
DC 5 V/1 A in
2 kg
0,5 kg
0,41 kg without batteries
104 x 104 x 80 mm (L x W x H)
