Attention: always unplug the appliance before you assemble to the fan.
Attention: the fan can only be used if complete with the support base.
For assembly refer to the diagrams: first place the front shell (D) on the body, then
the rear shell (C) and secure them with the hooks provided. Use the 2 screws (B1,
type #8x3/8") and the 4 screws (B2, type M5x1/2") provided. Insert the electrical
cable through the guide (A) in the rear shell.
After this has been done, check that the two shells are firmly and correctly
assembled.
Control panel
1. On/off button
2. Speed button
3. Ionising function button
4. Swing functionbutton
5. Timerbutton
USE
Before each use, verify that the unit is in good condition, the electric cord is not damaged, if the power
cord is damaged, it must be replaced by the manufacturer or a competent qualified electrician or a person
with similar qualifications, in order to avoid any risk.
The remote must be pointed at the display. Before using it, insert the batteries (open the
rear flap and insert 2 "AAA" batteries (not included) with correct polarity; close the
flap). Replacing all batteries at the same time is recommended. Do not mix used
batteries with new batteries. Should the remote control not be used for long periods of
time remove the batteries.
Plug the fan into the power outlet.
Running the fan:
1) To turn the fan on, press the "
2) In order to select the desired speed, press the "
control (minimum, medium or maximum), an indicator will light on the display corresponding to the
speed selected
manuals search engine
Remote control
1. On/off button
2. Speed button
3. Ionising function button
4. Swing functionbutton
5. Timerbutton
" (1) button on the control panel or the remote control.
" (2) repeatedly on the control panel or the remote
