Electrical installation

Voltage supply
Terminal data
Terminal data
Electrical connection
Possible connections
Bare end
Stop!
In order to avoid damages to the pluggable terminal strips and the contacts:
The terminal strips must be wired before plugging them in!
EDKMF2181 DE/EN/FR/ES/IT 2.0
Plug connector with spring connection
rigid: 2.5 mm
flexible:
without wire end ferrule
2.5 mm
with wire end ferrule, without plastic sleeve
2.5 mm
with wire end ferrule, with plastic sleeve
2.5 mm
10 mm
Electrical installation
2
(AWG 12)
2
(AWG 12)
2
(AWG 12)
2
(AWG 12)
2
2181FEW001G
