4. Operation:
Measurement
26 / 108
6. Switch on the mobile device with the on/off toggle
switch.
All LEDs light up temporarily.
9
Ready LED lights temporarily.
9
Ready LED flashes.
9
BAMO ready for operation.
9
If the error LED lights up permanently, there is a
hardware defect.
ü BAMO ready for operation.
1. Go to the locking device whose WaveNet accessib-
ility you want to test. In the process, close all doors
between the base station and the locking device to
be tested.
2. Set the Sig/Noise toggle switch to the Sig position
(signal measurement).
3. Hold the handset with its arm extended next to the
LockNode locking device.
4. Press the Activate button.
9 Signal strength is measured and displayed (see
table).
Data packet transmission is measured and
9
displayed (see table).
5. Repeat the signal strength measurement twice.
6. Set the Sig/Noise toggle switch to Noise (interfer-
ence signal measurement).
7. Hold the handset with its arm extended next to the
LockNode locking device.
WaveNet-Funktester
EN
