AEG PMR Voxtel R200 Handbuch Seite 6

6
Plug the mains adaptor into a 220V AC, 50Hz main socket.
Place the PMR units in the charge cradle in an upright position. The
charge LED indicators will light up.
It takes about 10 hours to fully recharge the batteries if they are
completely run down. New batteries take up to 14 hours to fully
charge.
Important:
The unit must be charged using the mains adaptor provided. Using
any other adaptor will result in non-compliance with EN60950-1 and
will invalidate any approvals and warranty.
Always turn off the PMR units when charging. This will shorten the
charging time.
3.4.2 Using the adapter (model R200/R210/R220) (see P5)
Lift the charge socket cover located on the upper side of the PMR.
Insert the round connector of the 9V DC / 200 mA adaptor into the
charge jack.
Plug the mains adaptor into a 220 V AC, 50 Hz main socket.
3.5 Battery meter
The battery meter is located in the left corner of the LCD screen. It
appears like a battery with three bars inside. These indicate the amount
of power available. When the battery level reaches it minimum level in
PMR on mode, the unit will emit two beep tones and automatically the
unit will power off.
The unit can detect the battery charge in 4 levels:
Battery charge at high level.
Battery charge at medium level.
Battery charge at low level. At this level, the unit will
emit a "beep" sound for every 10 seconds in normal
mode.
Important: Charge the unit for 10-14 hours.
