CONTENTS
•

Specifications

•
Features
•
Use of control panel
•
Use of remote control
•
Battery change
•
Warranty and communications
SPECIFICATIONS
1. Control panel
2. Plastic pedal
3. Shell
4. EVA* pedal
5. Socket
6. Remote control
7. Adaptor
*EVA stands for Ethylene Vinyl Acetate. This
is a type of black foam mat used on the two
footrest areas. It's very durable and provides a
comfortable cushioning effect.
Technical data
Power
Voltage
Max weight
Amplitude
Motor speed
Level
Heating
Product size
Packing Size
N.W. / G.W.
1
2
4
3
5
7
6
60W
24V 2A
40KG
4mm
1600r/min - 3500r/min
0-10
30 C - 50 C
o o
36,3 x 33,3 x 13 cm
41 x 38,5 x 17,5 cm
5 kg / 6 kg
FEATURES
Control panel
1. Increase temperature
2. Reduce temperature
3. Temperature display
4. Power
5. Speed display
6. Speed up
7. Speed down
Remote control
8. Power
9. Speed up
10. Speed down
11. Increase temperature
12. Reduce temperature
USE OF CONTROL PANEL
A B C
A. Press the button to turn on,
press it again to turn off.
The appliance will cause your foot
and ankle to pivot up and down to
simulate the motions of walking.
The rapid repeating pivotal motions
will help to loosen the joints in
your foot and ankle while causing
movement in the calf muscles which
helps to promote circulation in your
legs and feet. The pivotal motion
1 2 3 4 5 6 7
1
2 4
3 5
D E
created by the MotionCiser simulates
the motion of the foot, ankle, and calf
muscles just like when a person is
walking.
Adjust the speed
(level 1 - level 10)
At low speed the MotionCiser will
simulate the motions of around 400
steps, at mid speed around 600
steps and at full speed around 1,000
steps. The higher the speed settings,
