Technical data

General data
Type
Article number
Device dimensions without base (W x H x D) in cm
Weight (approximate) in kg
Display
Picture diagonal in cm/picture format
Resolution in pixels
Dynamic contrast ratio
Static contrast ratio
Viewing angle horizontal and vertical
Power consumption (EN 62087)
in operation (watt)
in standby (watt)
Ambient temperature (Celsius)
Relative humidity (non-condensing)
Air pressure
Electrical data
Chassis designation:........................................................................................... L 2710
Power supply: ........................................................................220 V – 240 V/50–60 Hz
Tuner:.................................................................................. VHF/UHF/cable/hyperband
Range:.......................................................................................... 45 MHz to 860 MHz
Station storage locations incl. AV and radio:.........................................................4000
TV standards:..................................................................................B/G, I, L, D/K, M, N
Colour standard:....................................... SECAM, PAL, NTSC, NTSC-V, PAL-V (60 Hz)
Sound standard .....................................................Mono/Stereo/2-Ton/Nicam B/G, I, L
......................................................Dolby Digital, Dolby Virtual Speaker, DTS
Audio nominal power (sine):.......................................................................2 x 20 watt
Teletext: ..........................................................................................TOP/FLOF Level 2.5
Page memory........................................................................................................2000
Digital teletext (only in UK / IRL with active MHEG-5 software).......................MHEG-5
Connections (max. equipment)
Mains socket: .....................................................................................Supply voltage
EURO-AV 1
EURO-AV 2
Downloaded from www.Manualslib.com
Individual 40 Compose Full-HD
67437xxx
101.4 x 61.7 x 10.3
31.5
FHD-LCD technology
101 / 16:9
1920 x 1080
10,000:1
2,000:1
178°
145
1,8
Video IN:....................................................................Y/C (S-VHS/Hi 8)
.................................................................CVBS (VHS/8 mm)
Video OUT: .............................................................CVBS (VHS/8 mm)
................................................................Y/C (S-VHS/Hi 8)
Audio IN: ........................................................................................L/R
Audio OUT:.....................................................................................L/R
Video IN:....................................................................Y/C (S-VHS/Hi 8)
.................................................................CVBS (VHS/8 mm)
.......................................................................................RGB
Video OUT: .............................................................CVBS (VHS/8 mm)
.........................................Y/C, (only with SVHS Link Plus)
Audio IN: ........................................................................................L/R
Audio OUT:.....................................................................................L/R
manuals search engine
+ +
100 Individual 46 Compose Full-HD 100
67439xxx
114.1 x 69.2 x 11.4
35.7
FHD-LCD technology
117 / 16:9
1920 x 1080
10,000:1
2,000:1
178°
165
1,8
5° – 35°
20 – 80%
800 – 1114 hPa (0 – 2000 m above sea level)
Jack 3.5 mm: .........................................................Headphones 32- 2000 ohm
Mini-DIN (AVS) Video IN:..............................................................Y/C (S-VHS/Hi 8)
............................................................CVBS (VHS/8 mm)
Cinch (yellow) Video IN:...........................................................CVBS (VHS/8 mm)
Cinch (white/red) Audio IN: ............................................................L (white) / R (red)
2x IEC socket 75 Ohm/5 V/80 mA:................................ Antenna/cable/DVB-T/C
2x F socket 75 Ohm 13/18 V/350 mA: ..............................ANT-SAT DVB-S/S2
2 x screw terminals Speaker Right: .....................................................+ (red) / - (black)
2 x screw terminals Speaker Left:........................................................+ (red) / - (black)
Jack 3.5 mm AUDIO IN2: ..............................................................................L/R
Cinch AUDIO IN max. 2Vrms:.......................................................Centre
2 x Cinch AUDIO IN1: ........................................................L (white) / R (red)
2 x Cinch AUDIO OUT (level depends on configuration):...L (white) / R (red)
Cinch COMPONENT IN:.......................................................Cb/Pb signal
Cinch COMPONENT IN:.........................................................Cr/Pr signal
Cinch COMPONENT IN:.............................................................. Y signal
Cinch AUDIO DIGITAL IN (SPDIF):........................................Digital audio
Cinch AUDIO DIGITAL OUT (SPDIF): ....................................Digital audio
SUB-D AUDIO LINK:.............................................................. Multi-sound
SUB-D PC IN:..............................................................PC/STB video signal
SUB-D RS-232C: ................................................................serial interface
Mini-DIN SERVICE: .................................................................. Service/L-Link
Mini-DIN CONTROL: .................................................Rotating stand control
2 x USB USB 2.0:.................................................. Standard JPEG/MP3 files
2 x HDMI Digital Video/Audio IN
Type A 19pole Standard 1.3:....................Digital video and audio
2 x CI-Slot Common Interface ......................................... Slot for CA module
52
+
Individual 52 Compose Full-HD 100
67440xxx
130.8 x 78.5 x 12.8
52.0
FHD-LCD technology
132 / 16:9
1920 x 1080
10,000:1
2,000:1
178°
180
1,8
