CARE & CLEANING CARE & CLEANING
CAUTION

WASHING INSTRUCTIONS

WASHING INSTRUCTIONS
• Do not use benzene, thinner or scouring powder.
• Use only soap ( pH7) or neutral household detergent.
• Do not use water hotter than 40°C.
Remove Air Filter
1 1
Press the knobs. Press the knobs.
2 2
Slowly pull down Slowly pull down
the intake grille. the intake grille.
3 3
Remove the air fi lter Remove the air fi lter
from the tabs and pull it from the tabs and pull it
downwards. downwards.
Air Filter Maintenance
Cleaning is needed when:
AUTO
FAN SPEED
AUTO
COOL DRY
AIR SWING
AUTO 123
POWER
TIMER
FILTER
F567156.indb 11 F567156.indb 11
Downloaded from www.Manualslib.com
• Switch off the power supply before cleaning.
• Do not touch the aluminium fi n, sharp parts may cause injury.
FAN
"FILTER RESET" appears on
FILTER
RESET
the remote control display.
(For wired remote control)
"FILTER" lights up on the
indicator display.
(For wireless remote control)
AUTO
manuals search engine
HINTS HINTS
• Clean the fi lter regularly for best performance and to
reduce power consumption.
• Please consult your nearest dealer for seasonal
inspection.
INDOOR UNIT INDOOR UNIT
Wipe the unit gently with a
soft, dry cloth.
Remove Remove

AIR FILTER

AIR FILTER
Vacuum, wash and dry.
• lt is recommended to clean the air fi lter every 6
weeks.
• After the air fi lter is cleaned, press
reset.
• Do not operate without an air fi lter.
• Wash/rinse the air fi lter gently with water to avoid
damage to the air fi lter surface.
• Do not dry the part with a hair dryer or a stove.
• Replace any damaged air fi lter.
Air Filter Installation
1 1
Insert the air fi lter
to the tabs of the
intake grille.
2 2
Slowly bring
up the intake
grille.
3 3
Knob
Press the knobs to the
CLOSE side.
/ to
FILTER RESET
FILTER RESET
11/24/2009 11:22:29 AM 11/24/2009 11:22:29 AM
11
