COMMANDER SE QUICK START
TERMINAL CONTROL
1
2
3
4
V
5
6
7
8
9
10
11
12
13
14
15
16
KEYPAD CONTROL
Connect terminals 7 & 9
key. Use and
O
key to reverse and
Improper procedures can result in personal injury or equipment damage.
Use this Quick Start Guide only if you are familiar with standard safety
precautions common to electronic drives. See Commander SE User
Guide for details.
manuals search engine
0V common
Local voltage speed reference input (A1)
+10V reference output
0V common
Remote current speed reference input (A2)
Analog output (Motor speed)
+24V output
Digital output (Zero speed)
Drive Enable / Reset
Run Forward
Run Reverse
Local (A1) / Remote (A2) speed reference
Jog Select
+24V output
OK
7
9
keys to increase/decrease speed. Press
key to stop.
1
FAULT
+24V
Drive Enable
I
key to go.
